Input voltage range 180Vac to 264Vac Normal voltage range 200Vac to 240Vac
Frequency range 47Hz-63Hz
Max input ac current 22A max.at full load condition
Leakage Current Less Than 0.5mA
@240Vac input
Normal output power 2800W
Regulation output power range 500-2800W(Continued work,optional)
Max.endure input voltage 300Vac
Rated Output Anode HV 5100Vdc
Rated Anode Output Current 840mA
Rated Filament Voltage 3.3V
Rated Filament Current 15A http://www.microwave-world.com
