Input voltage range 180Vac to 264Vac Normal voltage range 200Vac to 240Vac
Frequency range 47Hz-63Hz
Max input ac current 10A max.at full load condition
Leakage Current Less Than 0.5mA
@240Vac input
Regulation input power range 500-1600W
Max.endure input voltage 300Vac
Rated Output Anode HV 4200Vdc
Rated Anode Output Current 360mA
Rated Filament Voltage 3.3V
Rated Filament Current 10A http://www.microwave-world.com
