Analog Channels Measurement
Frequency Range: 5MHz~870MHz
Channel Range: Customized
Resolution: 10KHz
Bandwidth: 280KHz
RF Level
Input Range: 25~120dBuV
Accuracy: +/-1.5dB(25+/-5 degree C)
Resolution: 0.1dB
Detection: Peak
C/N
RF Input Range: >50dBuV
Accuracy: +/-2dB
Resolution: 0.1dB
Tilt
Maximum channels supported: 10
Resolution: 0.1dB
Channel scan/Limit test
Max. numbers of channel scan: 150
Supported limit test: Max/Min video, delta video, delta V/A, power etc.
Rail Voltage
Input Range: 0 ~100V AC/VDC
Accuracy: +/-2V
Resolution: 0.1V
Spectrum
Bandwidth: 8/16/32/100/200/500MHz, full


Digital Channels Measurement
Frequency Range: 5MHz~870MHz
Standard: DVB-C/ITU-T J.83 Annex A/B/C
Demodulation: 16/32/64/128/256QAM
Digital Power Range: 30~110dBuV
Accuracy: +/-2dB
Bandwidth: Adjustable
Symbol Rate: 1~7Ms/s
Constellation: support
MER:19~40dB
BER:1.0E-3~1.0E-8
