Material specificaiton: Housing Material: high temperature thermoplastic , UL94V-0 Rated.
Contact Material: brass or copper alloy
Plating: Gold plating over nickel
Shell: steel main material
USB Version: 3.0
Electrical performance:
Voltage Rated: 30V AC/DC
Current Rated: 1.0A AC/DC Max
Dielectric strength: 100V AC for 1 minute Between adjacent terminal, no breakdown.
Insulation Resistance: 100 Megohm Min,100V DC for 1 minute between adjacent terminal
Contact Resistance: 50 milliohm Max
Operation temperature: -25°C-85°C
