basic information size range DN15~200mm (1/2"~8")
working pressure PN1.6~6.4Mpa
suitable temperature -29-250?
Suitable medium water, gas, oil
CF8(304): suitable for nitric acid
CF8M(316): suitable for acetic acid
Technical Standard
Design Standard DIN 3357/1, 2EN12516-1
pressure-temperature rating GB/T12224, ANSI B 16.34
Face to face standard DIN3202F1(DN15-DN100)/F7(DN125
-250)/F17, F4(DN15-100), F5(DN125-DN250)/F18
End flange Std DIN2542-DIN2545, EN1092
Test Standard GB/T13927, ISO5208, API598, API6D
Material WCB, A105, CF8(304), CF8M(316)
Operated way Manual, Gearcase, Pneumatic, Electric
