Item Input powder voltage(V) Rated input powder capacity(KVA) Input voltage frequency(Hz) No-load voltaga(V) Output current range(A) Rate output voltage(V) Duty cycle(%)(25?) No-load loss(W) Efficicency(%) Power factor COSf Insulation class Weight(KG) Overall dimension(mm) Protection class Drive adjustment range(A) Diameter of rod(mm)ARC400 (three phase) AC380±15% 18 50/60 72 40-400 36 60 200 85 0.93 F 32 565×283×495 Ip23 0-100 1.6-6
ARC500 (three phase) AC380±15% 25 50/60 72 40-500 40 60 200 85 0.93 F 59.2 670×335×633 Ip23 0-100 1.6-6
ARC630 (three phase) AC380±15% 35 50/60 72 40-630 44 60 200 85 0.93 F 61 670×335×633 Ip23 0-100 1.6-8
