N series connector is a kind of threaded connection with low power. It widely applies to radio equipments and instruments for connecting RF coaxial cables. It can exchange with the international like product. Electrical Characteristics:
Characteristic Impedance: 50O
Frequency Range: 0-11GHz
Contact Resistance:
Inner conductor: =1.0mO
Out conductor: =0.2 mO
Insulation Resistance: =5000MO
VSWR: =1.30
Durability: 500 cycles
Material and Finishing:
Center Contact:
Pin-------brass, gold or silver plated
Jack------Phosphor bronze or beryllium bronze, gold or silver plated
Body and other metal parts: brass, nickel or ternary alloy plated
Insulator: PTFE
Gasket: Silicone Rubber
