Features:1) Compact Size, Light Weight
2) Fully Programmable, High Fidelity, Research Grade Performance
3) 12-Lead/3-Channel Two Recording Modes Switchable By Changing Patient Cable
Made From Bullet-proof Material
4) Lower Power Consumption
5) Lightning Data Transfer
6) Pacemaker Detection
Functional
Channels…………………………………………………8 Channel Digital Recording
Resolution ………………………………………………8, 10, 12, or 16 Bit Sampling
Recording…………………………………………………Full Disclosure, No Data Compression
Data Transfer……………………………………………Embedded USB connector or Removable SD Card
Sample Rate……………………………………………128-1024 Samples Per Second
Frequency Response…………………………………0.05Hz to 60Hz @ -3db
ECG Signal Verification………………………………LCD at Hook-up or on Demand
Memory
Recording Time…………………………………………24H, 48H
Type………………………………………………………Nonvolatile, SD Card
Capacity…………………………………………………Up to 2048 MB (Removable)
Physical
Dimensions………………………………………………2.68’’×2.08’’×0.63”
