ATP200-S12 12V/13A/156W 204WATP200-S24 24V/7.5A/180W 216W
ATP200-S48 48V/3.8A/182.4W 240W
ATP200-S56 56V/3.57A/200W 250W
General Specification
Line Regulation: +/- 1%
Load Regulation: +/- 5%
Efficiency: >83%, >85% for 56V
Safety Ground Leakage Current (Class I @230VAC 50Hz) <3.5mA
Over Voltage Protection: Latch Off(110~170%)
Over Load Protection: Hiccup/Auto Recovery (110%~200%)
Short Circuit Protection: Hiccup/Auto Recovery
Operating Temperature: 0-50 degree C
Storage Temperature: -40~85 degree C
Storage Humidity: 5% ~ 95% RH
Safety and EMC: UL, cUL, CB, CE
