Features:
According to DIN 18 251 class3
For wooden or steel doors
For single-leaf doors
Optional for rebated or non-rebated doors
Suitable for external fire and smoke protection door
Prepared for profile cylinders
With key action
Deadbolt 2-turn

Technical data
Follower 7mm 8mm 9mm
Distance 72mm
Backset 50/55/60/65mm
Forend
Type: Round head Square head
Thickness 3mm
Width 20/ 22/ 23 /24mm

Forend finish
Stainless steel: Satin stainless steel, Polish stainless steel
Vacuum metalizing: Satin brass, PVD, AB, AC.

Accessories
Striking plate
Pocket
Lock and striking plate fixing screw
