ETA-M3 led chip mounter:Specifications
M 3
M 5
PCB Size
30x30~1250x300mm
50x50~550x350mm
PCB Thickness
0.38~4.5mm
0.38~4.5mm
Placement Speed
24000CPH
16000CPH
Gantry Number
1
1
Spindle Number
4
4
Placement Accuracy
+/-50 µm @µ+ 3 sigma
+/-50 µm @µ+ 3 sigma/Chip,+/-40 µm @µ+ 3 sigma/QFP
Component Range
0402~14mm IC,BGA
0402~42mm IC,BGA,CSP,72mm Connector
Component Height
=10mm
=15mm
Feeder Inputs
15PCS
15PCS
Conveyor Direction
L?R
L?R (Option: R?L)
Nozzle Change
Manual
Auto
Convey Time
3S
3S
Mark Camera
0.18S
0.18S
