Electrical Specification
Frequency Range-MHz
1575.42+/-3 1602
Bandwidth-MHz +/-5+/-1
Gain-dBi 33+/2.5
VSWR =1.5
DC Voltage -V 2.2-5
DC Current 5-15mA
Noise Figure -dB =1.5
Nominal Impedance-O 50
Polarization RHCP
Max. Power-W 50
Noise Figure 1.5dB

Frequency Range-MHz 15681
Bandwidth-MHz CF1
Gain 5dBic(Zenith)
LNA Gain-dBi 282.5
VSWR =1.5
DC Voltage -V 2.2-5
DC Current 16-32mA
Noise Figure -dB =1.5
Nominal Impedance-O 50
Polarization RHCP
Max. Power-W 50
Noise Figure 1.5dB
Filter Insertion Loss =3dB
Mechanical Specification
Cable Length -m RG58,10m
Connector TNC Male
Antenna Dimension-mm
93.5*133.3
Weight-g 75
Mounting Screw
Temperature-? -40~+85
Humidity-? 5~95
