Brand:LCT
Send Inquiry
Rated loading:0.3Kg~3kg Dimension:10*33*110mm
Rated Output:1.0mv/V±10%
Zero Balance:±0.05R.O.
Non-linearity:±0.02%R.O.
Hysteresis,Repeatability:±0.015%R.O.
Creep in 2 Min.:±0.015%R.O./2Min
Temp.Effect on Output:±0.03%R.O./10?
Temp.Effect on Zero:±0.05%R.O./10?
Input Resistance:405±10O
Output Resistance;350±3O
Safe Overload:150%R.C.
Insulation Resistance:=2000MO
Compensated Temp. Range:-10to+40?
Operating Temp. Range:-20to+60?
Excitation,Maximum:18VDC
Cable,Length:f4mm*25cm
