Price:Negotiable
Brand:LCT

Send Inquiry

1?Features
Material:Aluminum alloy

Application:Mainly used for crane scales,hopper scales,tensile testing etc.

2?Specifications

Rated loading:5,10,20,30,50,100,200kg

Dimension:W*50.8*H

Rated Output:2.0mv/V±10%

Zero Balance:±0.02R.O.

Non-linearity :±0.03%R.O.

Hysteresis,Repeatability:±0.02%R.O.

Creep in 30 Min.:±0.03%R.O.

Temp.Effect on Output:±0.03%R.O./10?

Temp.Effect on Zero:±0.05%R.O./10?

Input Resistance:405±10O

Output Resistance:350±3O

Safe Overload:150%.R.C

Insulation Resistance:=2000MO

Compensated Temp. Range:-10to+40?

Operating Temp. Range:-20to+60?

Excitaction,Recommended:5~12VDC

Cable,Length:f5mm*2m
