1?Features
Material:Aluminum alloy

Application:Mainly used for price computing scales,counting scales,platform scales etc.

Max.platform size:400*500mm

2?Specifications


Rated loading:60,100,200,300,350,500Kg

Dimension:40*45*150

Rated Output:2.0mv/V±5%

Zero Balance:±0.05R.O.

Non-linearity:±0.015%R.O.

Hysteresis,Repeatability Error:±0.01%R.O.

Creep in 30 Min.:±0.02%R.O./30Min

Temp.Effect on Output:±0.02%R.O./10?

Temp.Effect on Zero:±0.02%R.O./10?

Input Resistance:405±10O

Output Resistance;350±3O

Safe Overload:150%.R.C.

Insulation Resistance:=5000MO

Compensated Temp. Range:-10to+40?

Operating Temp. Range:-20to+60?

Excitaction,Recommended:5-12VDC

Cable,Length:f5*1.5m
