Wavelength: 830nmOptical fiber type: 4µm SM optical fiber (optional)
Maximum output power: 3mW
Optical fiber connector: N
Applications: Others
Optical Data
Tolerance of ?: ± 10nm
Wavelength stability coefficient: ~0.3 nm/Degrees
Fiber Data
Core diameter: 4µm
Numerical aperture: 0.12
Electrical Data
Operating current: 35mA
Threshold current: 15mA
Slope efficiency: 0.6 mW/mA
Operating voltage: 1.9V
Monitor Current: 0.5mA
PD Reverse Voltage: 30V
Others
Operating temperature: +10~+30 Degrees
Storage Temperature: -20~+80 Degrees
Lifetime: >10000h
