Wavelength: 405 nm
Optical fiber type: 50/125µm multimode optical fiber (optional)
Maximum output power: 175 mW
Optical fiber connector: SC
Applications: Medical use;UVCTP;
Coupling efficiency is high, spot of good quality, stable performance, long life

Optical Data
Tolerance of ?: ± 5 nm
Spectral Width (FWHM): <3nm
Wavelength stability coefficient: ~0.3 nm/Degrees
Fiber Data
Core diameter: 60µm
Numerical aperture: 0.12
Connector type: SC
Electrical Data
Operating current: 200mA
Threshold current: 45mA
Conversion efficiency: 17.5%
Slope efficiency: 1.3 mW/mA
Operating voltage: 4.8V
Others
Operating temperature: 10~30 Degrees
Storage Temperature: -20~+80 Degrees
Lifetime: >10000h
