Technical Parameter:Rated Load: 5~125klb
Sensitivity:
(3.0±0.1%) m V/V
Combined Error:
±0.03% F.S
Creep Error30min:
±0.02% F.S
Zero Balance:
±1% F.S
Tco:
±0.02% F.S/10
Tc Span:
±0.02% F.S/10
Input Resistance:
750±5O
Output Resistance:
703±2O
Insulation Resistance:
=5000MO
Operating Temperature Range:
-30~+70
Maximum Safe Over Load:
150%F.S
Ultimate Over Load:
250%F.S
Recommend Excitation Voltage:
10~12V DC
Maximum Excitation Voltage:
15V DC
Sealing Class:
IP67/IP68
Element Material:
Alloy Steel/ Stainless Steel
Cable:
Length=L:12m
Citation:
GB/T7551-2008/ OIML R60
Mode Of Connection:
Red(Input+),Black(Input-),Green(Output+),White(Output-)
