Technical parameter:Rated Load: 1/5/10/20/30/40/50t
Rated Output:
1000000
Baudrate:
9600 Baud
Measuring Rate:
80/sec
Communication Mode:
RS485/4-wire
Combined Error:
±0.03% F.S
Creep Error30min:
±0.02% F.S
Zero Balance:
±1% F.S
Temp. Effect On Zero::
±0.017% F.S/10
Temp. Effect On Span::
±0.017% F.S/10
Insulation Resistance::
=5000MO
Operating Temperature Range:
-30~+70
Maximum Safe Over Load:
150%F.S
Ultimate Over Load:
250%F.S
Recommend Excitation Voltage:
10~12V DC
Maximum Excitation Voltage:
15V DC
Sealing Class:
IP67/IP68
Element Material:
-A: Alloy Steel, -SS: Stainless Steel
Cable:
Length=12m(7.5~22.5t), 18m(30~300t)
Citation:
GB/T7551-2008/ OIML R60
