Description:Technical Parameter:
Rated Load: 1/3/5/10/25/35/50/75klb
Sensitivity:
(2.0±0.1%) m V/V
Combined Error:
±0.03% F.S
Creep Error30min:
±0.03% F.S
Zero Balance:
±1% F.S
Temp. Effect On Zero:
±0.03% F.S/10
Temp. Effect On Span:
±0.03% F.S/10
Input Resistance:
750±5O
Output Resistance:
700±2O
Insulation Resistance:
=5000MO
Operating Temperature Range:
-30~+70
Maximum Safe Over Load:
150%F.S
Ultimate Over Load:
250%F.S
Recommend Excitation Voltage:
10~12V DC
Maximum Excitation Voltage:
15V DC
Sealing Class:
IP67
Element Material:
Alloy Steel, Stainless Steel
Cable:
Length=L:12m
Citation:
GB/T7551-2008/ OIML R60
Mode Of Connection:
Red(Input+),Black(Input-),Green(Output+),White(Output-)
