Price:Negotiable

Send Inquiry

Marking
Jacket marking: As you like
Description
Rated Temperature (?): 70
Application
Telephone and other communication circuits such as voice, data, and audio for on-premise customer systems.
Reference Standard
The customer's specification.
Construction

Conductor
Solid Stranded Bare Copper

4 Twisted Pairs
8C

AWG
23

Construction (mm)
1/0.575

Stranded Dia.(mm)
0.575

Insulation
PE

Nom. Thickness (mm)
0.224

Insulation Dia.(±0.05mm)
1.024

Center Cross


Rip cord
Nylon

Jacket
PVC

Nom. Thickness(mm)
0.65

Outer Dia.(±0.2mm)
6.5



Weight(kg/1000ft)
15

Package (cm)
40x40x25 pull box

Color
Insulation
Cores: Pairs
1P: Blue & White/Blue
2P: Orange & White/Orange
3P: Green & White/Green
4P: Brown & White/Brown
