1) reasonable price 2)15years`experienced manufacturing
3) perfect equipment
Square cbb61 capacitors 450V
Specifications
1) Climate type: 25/85/21
2) Capacitance tolerance: +/-5%
3) Explosion Class: P0, P1
Highly quality specifications
Features:
1. Widely used for AC single phase motors for running
2. Highly quality specifications
1) Climate type: 25/85/21
2) Capacitance tolerance: +/-5%
3) Testing voltage: A) Between leading-out: 1.75UR, 10S no breakdown
4) Between leading-out end and shell: 2200 VAC, 10S no breakdown
5) Insulation resistance: A) Between leading-out ends: = 3000 MO
6) Between leading-out end and shell: = 1000 MO
7) Loss tangent: Tgd = 0.002( 50/60Hz)
8) Working Class: C, D
9) Explosion Class: P0, P1
Widely used for water pumps, cleaning machines, washing machines, single-phase motors with small and light weight, have long lifespan and good self-healing.
