LED dot matrix display with light-emitting diodes as pixels, it uses high-brightness LED chip array assemblies were then made through the epoxy resin and mold package. With high brightness, low power consumption, pin count, large viewing angle, long life, moisture resistance, hot and cold, corrosion resistance and so on.Technical Parameters:
Item No./Model PH8
Pixel Composition 1R1G1B
Pixel (mm) 8
Density(dots/m2) 15625
Brightness(cd/m2) 1800
Viewing Distance(m) =8
View Angle H:150°,V:150°
Gray Scale(level) 4096
Consumption(Max) 900W/m2
Consumption(Average) 550W/m2
Display Card DVI card
Control Mode Synchronous
Drive Mode Static constant current
Refresh Rate(HZ) 420
Working Temperature(?) -25-- +85?(for working)
Working Humidity 10%-95%RH
Model Size(mm) 256*128
Cabinet Size(mm): 1024*768
Cabinet Dimension(m2) 0.786
Cabinet Weight(KG) 38
Cabinet Resolution(dots) 128*96
Cabinet Material Steel/Aluminum
Lifespan 100,000 hours
