Power supply: It can be powered directly by Solar panel; DC electric source; battery.
Specification:
Model Working voltage Working current Static lift Static flowrate Temp Remarks
38#-21b 6VDC 1500mA 2.5 meter 7 L/min =100degC
12VDC 1500mA 5 meter 9 L/min =100degC
24VDC 1000mA 7 meter 10 L/min =100degC
The tolerance of technical parameters above is ±10%
Remarks:The technical parameters above are only for your reference, please provide us your required specifications. For more detailes, please feel free to contact us.
Structure dimensions
Model Dimension(mm) Inlet OD(mm) Outlet OD(mm) Remarks
38#-21b 62.5*48*85 15.5 10.5 Outlet and inlet have antislip strip
