· UCIS Infinity Independent Achromatic Optical System· WF10x plan eyepieces,20mmfield of view, high eye point up to21mm
· Seidentopf binocular viewing head; inclined45º
· 52-75mminterpupillary distance settings ±5 Diopter adjustment
· Quintuple nosepiece inward facing with positive click stops
· Infinity long work distance plan Achromatic 10x, 20x, 40x and Infinity long work distance phase-contrast 20x objectives
· Right hand controls, low position, fixed stage,240mmx260mm, movement range135mmx85mm
· N.A. 0.30Abbe condenser with iris diaphragm, with phase-contrast slide, long work distance72mm.
· Coaxial coarse and fine focus mechanism with markings. Fine focus sensitivity0.001mm
· 6 volt 30 watt halogen illumination
· Fluorescence illumination system: 100W mercury lamp house and power supply, B/G/UV/V fluorescence filter block
· Dust cover, power cord
