The Agilent 8720ES Vector Network Analyzer allows complete characterization of RF and microwave components. The 8720ES includes an integrated synthesized source, test set and tuned receiver. The built-in S-parameter test set provides a full range of magnitude and phase measurements in both the forward and reverse directions. Built-in vector accuracy enhancement techniques include full two-port, adapter-removal, and optional TRL calibration.Some featrues of the Agilent 8720ES
S-Parameter Netork Analyzer are:
• 50 MHz to 20 GHz
• 100 dB of dynamic range
• Excellent measurement accuracy
• Two measurement channels
• Four display channels
• Frequency and power sweeps
• Fast sweep and data transfer speed
• Pass/Fail testing, powerful marker functions
• Electronic calibration (ECal)
• Internal automation with test-sequencing
• Optional time-domain, high power test set, four samplers and TRL calibration, direct sampler access, frequency-offset mode
