It’s precision level can up to 0.3%,which is enough to resist various interference waves,the transmitter is a non-contact one and does not contact liquid diectly.so the fault rate is low.1.Rrange: 0~15m
2.Blind area: 0.2m~0.5m
3.Accuracy: 0.25%
4.Direction angle: 4-6 (full angle)
5.Pressure: Less than four atmospheric pressure
6.Display: LCD display built-level height or distance
7.Digital output: RS485 Interface, ModBUS agreement or custom
8.Analog Output: 4-20Ma
9.Switching capacity: 2 Way AC220V/3A
10.Supply voltage: two-wire DC24V 120mA/AC220V 5W
11.Ambient temperature: -20C~+60C
12.Protection grade: IP67
13.Proof-explosion grade: Exd (ia) IIBt6
14.Installation: Flange
15.Shell material: Aluminum Die Casting,proof-explosion shell
