Brand:fisher
Quantity:1000
Send Inquiry
Main Valve Pressure RatingsMaximum Operating Inlet Pressure: 1050 psig / 72,4 barMaximum Operating Differential Pressure: 800 psig / 55,2 bar dMaximum Emergency Inlet and Differential Pressure: 1050 psi / 72,4 barOutlet Pressure Ranges6-inches w.c. to 1000 psig / 15 mbar to 69,0 bar
Pressure RegistrationExternal
Temperature Capabilities-20° to 260°F / -29° to 127°C
Approximate WeightsCast iron : NPS 2 x 1 to 6 / DN 50 x 25 to 150: 50 to 225 Pounds / 23 to 102 kg depending on body size and end connection style
WCC or LCC Steel: NPS 1 to 8 / DN 25 to 200:22 to 1590 Pounds / 10 to 721 kg depending onbody size and end connection style
Construction with Integral Slam shut:
NPS 1 to 6 / DN 25 to 150, flanges end connection only:44 to 537 Pounds / 20 to 244 kg depending on body size and flanged end connection style
Position Monitor Bracket (PMB) SpecificationsConstruction Materials: Bracket:304 Stainless steel Hardware: 18-8 Stainless steel
