Input voltage range: 90V-132Vac/180-264Vac selected by withch 47Hz-63Hz
Input current: 3.8A/115Vac 2A/230Vac
Inrush current: cold start current 35A/115Vac 60A/230Vac
Leakage current: <0.5mA/240Vac
Adjustable range for DC voltage: ±10%radet iytoyyt voltage
Overload protection
Setup, rise hold up time: 200ms 100ms 20ms
Withstand voltage: 1min I/P-O/P 1.5KVI/-FG 0.5KV O/P-FG0.5KV 1min
Working temperature and humidity: -10 - +60 20%-90%RH
Safety standards: GB4943 UL60950 En60950
EMC standards: GB9254 Ne55022
Weight/packing: 0.5kg 45pcs/22.5kg

No Type Output Eorror Waveandnoise Efficiency Power
JX1801 JX-120W-5 5V/0-35A ±2% 120mV 73% 180W
JX1802 JX-120W-12 12V/1-14A ±1% 120mV 76% 180W
JX1803 JX-120W-15 15V/0-11A ±1% 150mV 77% 180W
JX1804 JX-120Q-24 25V/0-7A ±1% 150mV 79% 180W
