No Output specification Wave and noise EfficiencyJX012-050150C 5V 1.5A 60mV 74%
JX012-090130C 9V 1.3A 90mV 78%
JX012-120100C 12V 1A 120mV 80%
JX012-150080C 15V 0.8A 150mV 80%
JX012-240050C 24V 0.5A 240mV 80%
JX012-360040C 36V 0.4A 360mV 82%
JX012-480025C 48V 0.25A 480mV 83%
Input voltage range: 90-264Vac
Rate voltage: 100-240Vac
Input current <0.3A
Inrush current <20A
Leakage current <1mA
Over load protection >2.5A
Over-voltage protection: 15V
Start: 100VAC<3S
Hold time: 240VAC>20mS
Withstand voltage: 3Kvac 5mA 1Min
Temperature:0 -+ 40
Humidity:20% -90% RH
Safety Standards: GB4943-2001 IEC60950
EMC: En55022
Size: 74.5*42*30mm
Output: 12V±5%
Efficiency: >=80%
Power: 12W
