Brand:Rapidcnc
Quantity:500
Send Inquiry
Technical parameters:No Description Parameter
1
effective working area:
300x300x60 mm
2
Table Size:
420x420mm
3
Positioning Accuracy:
±0.01/300mm
4
X,Y,Z repositioning Accuracy:
±0.05mm
5
Table Surface:
T-slot table
6
frame:
Cast Aluminum
7
X, Z Structure:
Round rails and TBI ball Screw,
8
Y Structure:
TBI Rail Linear Bearings and Ball Screw
9
Max. Power Consumption:
1.2Kw
10
Max. Rapid Travel Rate:
6000mm/min
11
Max. Working Speed:
4500mm/min
12
Spindle Power:
800w air cooling spindle
13
Spindle Speed:
0-24000RPM
14
Drive Motors:
Stepper system
15
Working Voltage:
AC220V/50/60Hz, 1PH
16
Command Language:
G code
17
Operating System:
DSP System (options: NC studio)
18
Computer Interface:
USB
19
Flash Memory:
128M(U Disk)
20
Collet:
ER12
21
Software Compatibility:
Type3/UcancameV9 software,(Option: Artcam software)
