Specification A11.0215-A A11.0215-B Eyepiece WF10X(F18mm)
Objective Achromatic 4X/0.10 Achromatic 4X/0.10
Achromatic 10X/0.25 Achromatic 10X/0.25
Achromatic 40X/0.65(Spring) Achromatic 40X/0.65(Spring)
Achromatic 100X/1.25(Spring, oil)
Head Monocular head 360° rotatable, inclination 30°
Focus System Coaxial coarse/fine focus system, Minimum division of fine focusing: 4um
Nosepiece Triple frontward ball bearing outer locating Quadruple (Frontward ball bearing outer locating)
Stage Fixed, 120x120mm, with 5 holes iris diaphgram Double layer mechanical, size 135x125mm, moving range 75x35mm
Collector For LED lamp
Light Source High brightness white LED lamp
