Performance and Characteristics:1.Natural or man-made fibre all can be used in this machine for making rope.
2.It can produce coils length from 440m-4890m.
3.It can produce or process the three-strand and four-strand ropes.
4.The machine can do twisting into multi-strand and rope making in one time.
5.High production speed , extremely high output.
Technical Parameters:
Rope range:3-10mm
Flyer speed:0-max,1200 rpm, depending on pre-twist factor
Rope Lay:S and z
Twists per minute :2 x rope flyer speed
Lay Length:7.6-45mm/130-22 twists per meter
Pre-twist factor:0.43-2.55 x rope twist
Take-up,coiling head:Ø 420 mm,adjustable traverse max.300 mm,barrel Ø135 mm
Take-up, max.weight:Polypropylene 20 kg
Pay-off packages:
M44/3
3x3,max.Ø250x300 mm traverse
3x1,max.Ø400x500 mm traverse
3x6,max.Ø170x250 mm traverse
M44/4
4x3,max.Ø250x300 mm traverse
4x1,max.Ø400x500 mm traverse
4x6,max.Ø175x250 mm traverse
