Engine Kaiwo 490
Engine model KD490
Rated power(Kw/rpm) 38/
The maximum torque(N.m/rpm) 173.9/1760
Exhaust volume(L) 2.545
Theory of consumption(g/kw.h) =255.7
battery voltage(V) 24
Battery capacity(AMP) 60Ah*2
output voltage of the generator(V) 28
engine output current(A) 750W
Drive axle Isuzu
Tire specifications 14/90-16
Brake system Drum brake
Hydraulic pump type CB-FC32 left
The operation way Mechanical
Material transport height(mm) 4160
Machine size(mm) 5400*1640*2670
The length of the whole(mm) 5400
Overall width(mm) 1640
The height of the whole(mm) 2670
The maximum length of the whole machine(mm) 5600
The maximum total height(mm) 2820
Minimum ground clearance(mm)
Bucket width(mm) 1700
Wheelbase(mm) 2250
Tread(mm) 1350
The standard device craper bucket
Optional device Grab
The basic performance load
Vehicle quality(KG) 2795
Rated load(KG) 1600
