Engine Changgong 22 Horsepower battery voltage(V) 12
Battery capacity(AMP) 100Ah
Drive axle 130
Tire specifications 750-16
Material transport height mm 2820
Machine size mm 4220*1230*2290
The length of the whole 4220
Overall width 1230
The height of the whole 2290
The maximum length of the whole machine 4400
The maximum total height 2440
Bucket width 900
Wheelbase mm 1770
Tread mm 1010
The standard device craper bucket
Vehicle quality KG 1620
Rated load KG 800
Rated capacity of bucket m³ 0.15
Unloading height - uninstall an angle of 45 degrees mm 1910
Unloading distance - discharging angle mm 1060
The rated capacity of bucket m³ 0.15
Vehicle quality KG 1620
Pick up the best KN 7.55
