Main capability characteristic :1.Drawing speed by frequency conversion.
2.Coordinate the speed with computer among the drawing ,annealing and closing lines .
3.Single receiving line, automatic changer double vertical take -off devices and wire -bound
set for users' matching.
4.These devices include wire drawing,annealing,cooling and drying .
Model : JDT-1000 SP-2
Suitable Material : Cu
Drawing Die : 13
Inlet wire Diameter (mm) : 8.0
Outlet wire Diameter Range (mm) : 1.2-3.0
The Highest Yield (kg/h) : 1000
Main Motor Power (kw) : 110
Drawing wire Machine Dimension (m) : 5*1.8*1.3
Annealing type : Tubular type annealing
Area of Size (m) : 17*2.5
Note : 1.Take -up way :single -disc collection lines,double-disc collection lines ,spooling
for customers' choice.
