Bore Sizes:NPS 1/2" to NPS 8"(DN15 to DN200)
Pressure Ratings:
CL150~CL600(PN10 to PN63)
Applications:
All kinds of severe applications which consist corrosive and (or) abrasive mediums, such as pneumatic conveying, limestone slurry in powerplant and some other similar conditions.
•Design and Manufacture: API 6D/API 608
•Face-to-Face Dimension: ASME B16.10 or on request.
•Flange Ends: ASME B16.5 RF or on request
•Pressure-Temperature Rating: ASME B16.34
•Inspection and Testing: API 598
•Body Material: Standard materail are forged steels such as A105, F304, F316, F304L, F316L, LF2, F51, F53, and cast steels are also available on request.
