Standard:According with GB/T983 E316L-16
Corresponding with AWS A5.4 E316L-16
Usage:It widely be used in stainless steel structures of equipment of urea, synthetic fiber or dissimilar stainless steel structure. Also it could be used in high Cr steel o special steels that cannot be PWHT.
Chemical Composition of Deposited metal (%)
Element C Mn Si S P Cu Ni Mo Cr
Specification =0.04 0.5-2.5 =0.90 =0.030 =0.030 =0.75 11.0-14.0 2.0-3.0 17.0-20.0
Actual Result 0.029 1.23 0.6 0.011 0.019 0.14 11.43 2.27 19.2
Properties of Deposited metal
Test Item Tensile Strength Rm (MPa) Elongation A(%)
specification =490 =30
Actual Result 580 41
Reference Current ( AC,DC+)
Welding Positions:
