Main Technical Parameters
Model CHCY -8/600C CHCY -8/800C CHCY -8/1000C
Printing width 600mm 800mm 1000mm
Max. width of materials 650mm 850mm 1050mm
Max. printing speed 120m/min 120m/min 120m/min
Max. machine speed 140 m/min 140 m/min 140 m/min
Max. diameters of winding and unwinding 600mm 600mm 600mm
Roll diameter 76mm 76mm 76mm
Printing roll diameter 120~300mm 120~300mm 120~300mm
Registering precision 0.1mm 0.1mm 0.1mm
Tension control range 3~25kg/FullWidth 3~25kg/FullWidth 3~25kg/FullWidth
Oven heating power 72Kw 96Kw 120Kw
Total power 109Kw 136Kw 160.5Kw
Machine weight 18000kg 20000kg 22000kg
Overall dimension L13300*W3200*H2500mm L13300*W3400*H2500mm L13300*W3600*H2500mm
