CW: 650nm808nm850nm980nm1060nm1310nm1480nm1550nmOptional nm
Operating Wavelength Band: ±40nm
Typical Insertion Loss: 0.4/0.5 dB
Maximum Insertion Loss:0.6/0.7 dB
Minimum Extinction Ratio:22/20 dB
Minimum Return Loss:50 dB
Minimum Directivity:50 dB
Power Handing:500 mW
Fiber Type :SMF-28 or PM Panda fiber on Port3
Load Tensile:5N
Operating Temperature:–5 to +70?
Storage Temperature:-40 to +85?
*All specifications above are for device without connector.
