CW: 808nm1550nm1310nm1064nm
Pass Band: ?± 4nm
Min. Isolation Loss @ WL<1054nm & >1074nm: 25 dB
Typ. Peak Isolation: 40(Grade P) 32(Grade A) dB
Min. Isolation in Band (at 25?): 30(Grade P) 25(Grade A) dB
Typ.Insertion Loss: 0.80 dB
Max. Insertion Loss (at 25?): 1.20 dB
Max. Polarization Dependent Loss: 0.15 dB
Max. Optical Peak Power: 1K 5K 10K 20K 200K optional W
Max. Optical Power (CW): 1 3 5 10 20 50 or Specify W
Min. Return Loss: 50 dB
Fiber Type: Hi1060, SMF28, 10/125, 15/130, 20/125, 20/400, 25/250, 30/250um optional
Tensile Load: 5N
Operation Temperature: -5 ~ +60?
Storage Temperature Range: -20 ~ +75?
