CW: 808/915/975nm
Operating Wavelength Range: ± 15
Typ. Pump Insertion Loss: 0.3 dB
Max. Pump Insertion Loss(-5~70?): 0.5 dB
Operating Signal Wavelength Range: 1020~1120nm
Min. Backward Signal Attenuation:40 dB
Max. Optical Power (CW): 7W/10W/25W
Min. Return Loss: 35 dB
Fiber Type: 250um Multimode Fiber, 105/125
Operation Temperature: -5 ~ +70?
Storage Temperature Range: -40 ~ +85?
Above specifications are for device without connector.
