CW: 915/975nm
Operating Wavelength Range: ± 15
Typ. Pump Insertion Loss: 0.3 dB
Max. Pump Insertion Loss(-5~70?): 0.5 dB
Operating Signal Wavelength Range: 1020~1120nm
Min. Backward Signal Attenuation:50 dB
Max. Optical Power (CW): 7W/10W/20W
Min. Return Loss:50 dB
Fiber Type: Hi 1060 Fiber
Operation Temperature: -5 ~ +70?
Storage Temperature Range: -40 ~ +85?
Above specifications are for device without connector.
