Center Wavelength: 850nm1060nm1310mn1480nm1550nm
Typical Insertion Loss in Band at 25 ?:0.3 dB
Maximum Insertion Loss in Band at -5~70?:0.5
Typical Extinction ratio at 25°C:30 dB
Minimum Extinction ratio at 25°C:28 dB
Minimum Return Loss:50 dB
Tensile Load:5N
Maximum Optical Power (CW):151020 or OpticalW
Operating Temperature:-5 to + 70?
Storage Temperature:-40 to +85?
* Above specification are for device without connector.
* For devices with connectors, insertion loss will be 0.3dB higher, RL will be 5dB lower and ER will be 2dB lower.
*The PM fiber and the connector key are aligned to the slow axis.
