Center WaveLength: 1064nm or OptionalOperating Wavelength Range: ±30nm
Working Distance: 5 or Optionalmm
Typical Insertion Loss @ 5mm: 0.25 dB
Maximum Insertion Loss @ 5mm: 0.3 dB
Typical Extinction Ratio: 25 dB
Minimum Extinction Ratio:22 dB
Minimum Return Loss:60 dB
Tensile Load:5N
Fiber Type: PM 980 Panda Fiber or Optical
Operating Temperature: -5 to +70?
Storage Temperature: -40 to +85?
*Above specifications are for device without connector. PM fiber & connector key are alignde to the slow axis.
*For devices with connectors, IL will be 0.3dB higher, RL will be 5dB lower, and ER will be 2dB lower.
