rocessing Capacity Max. swing diam. over bed 400
Max. swing diam. over slide 160
Max. machining diam. 360
Max. machining length 450
Bed Tilt Angle 45 o
Spindle
Taper of spindle bore A2-5
Chuck 6''
Spindle bore 56
Spindle speed 5000RMP
Feeding
X/Z axis travel 230/500mm
X/Z axis rapid moving speed 18/24m / min
Lead screw 3206/3206
Min. resolution 0.001mm
Motor
Spindle motor 5.5/7.5kw
X/Z-axis servo motor 2.5/2.5kw
Coolant motor 0.49kw
Hydraulic motor power 2HP
Tailstock
Tailstock travel 450
Tailstock quill travel 80
Tailstock quill dia. 72
Tailstock quill taper MT4
A.T.C
Turret type Hydraulic turret Y160
Turret capacity 8-position / 10-position
Tool shank size 20x20mm
Boring blade diameter 25mm
General
Power Capacity 10KVA
Overall dimensions 2500x1675x1800
N.W. 3200kg
