FAG B7022-E-T-P4S-UM bearing technical datasheet:Type: Angular contact ball bearings for spindles, super precision
Bore diameter: 110 mm
Outer diameter: 170 mm
Width: 28mm
Weight: 2 KGS/PC
Basic load rating: 110 Kn
Preload force: 2072N
B: Standard steel balls
70: Medium series
E: Contact angle 25•
T: Cage Laminated fabric, guidance on outer ring
P4S: FAG standard better than P4 to DIN 620
U: Individual bearings, suitable for any arrangement
M: Moderate Preload
Contact: sales(at)hzskf.cn
Skype: lovejoanna8
www.skfbearingshops.com
Feature: B7022-E-T-P4S-UM has better precision accuracy P4S than P4, it’s made from high quality material through specific heat treatment, a long material fatigue life and wear resistance is achieved with the result that the bearings can be run permanently in various machine tools.
Yakang Bearing Supplies is professional in distributing various FAG high precision spindle bearings.
