NSK 22320EAKE4 bearing technical datasheet: Type: spherical roller bearings, double row
Bore diameter: 100mm
Outer diameter: 215mm
Width: 73mm
Basic load capacity: 815Kn – 950Kn
Running speed: 2400 r/min – 3000 r/min
Weight: 13 KGS
Origin: made in JAPAN
EA: high load capacity, pressed steel cage
K: tapered inner bore 1:12
E4: outer ring with three oil holes and a oil groove
Prices: enquiry
Availability: 15 pcs in Stock list
Contact: sales(at)hzskf.cn
Skype: lovejoanna8
www.industrybearing.com
NSK HPS series Spherical roller bearings 22320 have increased roller size and number, EA is high strength pressed steel cage and high limiting speed cage flange by special surface treatment, the inner ring and outer ring have high-temperature operability.
There are many more Part no. of NSK spherical roller bearings stocked in Yakang Bearing.
