Rated line pull 4500lbs(2041kgs) single line
Motor Permanent magnet,1.4kw/1.9hp
Gear reduction ratio 135:1
Gear train 3 Stage Planetary
Cable (Dia x L) Diamete0.21”(5.4mm)Length41.3’(10.5m)
Control Remote switch
Drum size (Dia x L) 1.24”(31.5mm) x2.8”(71mm)
Clutch Sliding Ring Gear
Braking action Automatic In-The-Drum
Overall dimensions(L X W X H) 13.4”X4.3”X4.4”(353mmX110mmX112mm)
Mounting bolt pattern 166mm*76mm,Ø9
Weight N.W. 10 kg  G.W. 12 kg
Packing size 410mmx350mmx210mm  1PC/CTN
