Price:Negotiable
Brand:SSH
Quantity:10000000

Send Inquiry

ELECTRICAL
1. Current rating: 1.5 A
2. Voltage rating: 125V AC
3. Insulation resistance: 500M OMINI
4. Withstand voltage: AC 1000V RMS 50HZ or 60HZ 1 Minute
5. Contact resistance: 35-50M OMax
MECHANICAL
1. Insertion force: 2 contacts------350g 4 contacts------500g 6 contacts-----750g
8 contacts------900g 10 contacts-----1050g
2. Max strength: 75 N
3. Durability: 600 cycles with insert and pull Min.
4. Working temperature: from -40 centidegree to 70 centidegree
MATERIAL
1. Plastic housing: 1) ABS resin (UL94V-0)
2) Glass filled PBT (UL94V-0)2. Gold plating: 1) 0.45mm DIA phosphor bronze gold plating after nickel.
2) 0.35mm thickness phosphor bronze alloy selective gold plating after nickel
3.Shielding housing: 0.20mm thickness copper alloy with nickel plated
4.Thickness of gold plating: 3u Inch, 6u Inch, 15u Inch, 30u Inch, 50u Inch
